As part of my ongoing effort to get organized, I’ve been wanting to make a pegboard for my garage for a long time. I finally had some time recently and I think it turned out pretty well. This is a very basic woodworking project. I didn’t use any power tools except for a drill and just hand sawed a few pieces. It’s straightforward and an easy way to organize a garage, craft room, sewing room, or game room. I made mine 2′ x 4′, but there are larger pegboard options available and your local home improvement store. The directions would be the same, except for the changing dimensions.
* One 2′ x 4′ piece of hardwood pegboard (home improvement store, ~$15)
* Two 2″ x 2″ x 8′ furring strips
—- Cut one in half into two 4′ lengths
—- Cut second in half; then cut one piece in half again to get two 2′ lengths (you’ll have an extra 4′ piece)
* 15 – 20″ long piece of scrap 1″ x 4″ or similar wood to make a french pleat
* Box of 1.5″ wood screws (you’ll need ~20-30)
* Power drill
* Basic supplies – tape measure, level, pencil, etc.
The overall plan for the pegboard is to create a frame of furring around the outer edge behind the pegboard material. The furring strips will be attached to the board and to each other to create a strong frame with the pegboard that is held away from the wall a sufficient amount to allow you to hang hooks through the holes without your wall getting in the way.
To start the construction, place the furring strips in a rectangle on the floor or a sturdy surface with the pegboard on top. The assembly should look as it would on the wall. For each furring strip, carefully align it to make sure everything is straight and aligned with the pegboard and drive screws from the front of the pegboard, through a hole and into the furring strip. The head of the screw should not fit through the hole and should secure it to the frame of furring strips. I put about 4 to 6 screws on each of the 4 sides. Once all of the furring strips is attached to the pegboard, flip over the board and secure the furring strips to each other at the corners for added rigidity.
At this point, you should have your pegboard essentially assembled. If you want to spray paint the whole thing, now is the time. (I kept this one au naturel since it was for the garage, but am considering a white one for my craft room. That’s for another weekend…)
The next step is to hang the pegboard on your wall of choice. Feel free to hang this however you’d like, but I’d recommend a french pleat. The whole assembly has some weight to it, so you’ll need something stronger than hooks or nails. The french pleat is a good solution because it provides a hardy hanging surface. This technique is frequently used hang headboards when they do not attach to the bed frame.
You can find a lot of tutorials in the blogosphere about french pleats. They are pretty simple if you have a good picture. Here’s my attempt of a descriptive photo:
HoustonDIY’s introduction to a French Cleat
The key is find a piece of scrap wood that is ~1 – 1.5″ thick. depending on the shape and weight of your pegboard, you can either create a long french cleat across the whole length of the piece you’re hanging, or you can use two pieces on each edge like I did. I found a 1″ x ~18″ piece of scrap in my garage. I first cut it in half on the short length to create two 1″ x ~9″ pieces. Then, using a miter box or table saw, cut a 45 degree angle cut through the shorter length of each piece. If you are using one large cleat, cut a 45 degree cut down the entire length of the piece, the long way.
Then, the method will be to attach one piece that you just cut to the wall and the other, matching piece attaches to your pegboard. The key is to make sure the piece attached to the wall is oriented with the cut, angled edge upward and with the higher side away from the wall. This creates a triangle shaped ridge at the top of the piece of wood on each side of where the peg board will go (or along the entire length, if using one large cleat). Then, attached the matching piece of wood to your pegboard oriented downward with the longer side away from the pegboard. Then, you can easily hang the pegboard by setting it onto of your french cleat. This makes the item very secure but easy to hang and remove. Make sure to attach the wall cleat to a stud with 2 to 4 screws. If using a long cleat, attach at every stud with at least 2 screws.
I found making this DIY pegboard was an easy and fun way to get organized. The key was to figure out what size I wanted and how to hang it. Once I mastered the french cleat, and with some rigorous measuring to make sure it would be level, my pegboard was wonderful and put to use right away. You can also cut the peg board to make the personalized pegboard that fits your space. Happy DIY-ing!
DIY pegboard proudly displayed in my garage
